Application
Oil Sector, Refineries, Chemical Plants, Fertilizers and Fire Tenders etc.
Features
| Materiel |
: |
Seamless Mild Steel Tubes |
| Size of Monitor |
: |
63 mm |
| Size of Inlet Flange |
: |
80 mm |
| Construction |
: |
Welded From M.S. Seamless Pipes, Bends, etc. |
| Discharge Capacity |
: |
1750 LPM |
| Horizontal Throw |
: |
50 - 55 Meters |
| Rotation |
: |
360 o |
| Elevation |
: |
58 o to 30 o |
| Joint |
: |
Swivel Type (Gun-Metal) |
| Jet Spray Nozzle |
: |
Gun Metal or Aluminium |
| Operative Pressure |
: |
0.7 N/mm2 at Nozzle End |
| Leakage Pressure |
: |
To withstand a pressure of 2.3 N/mm2 |
